25. Slide the finisher [A] along the rail of the bottom plate from the left-hand side of the
machine to attach it ( ×1).
• Hold the front side [A] of the internal finisher as shown below to check if the internal finisher is
correctly set in the rail of the bottom plate.
26. Reattach the left rear cover.
