6. Attach the keyboard stand bracket [A] on the front upper cover ( x3).
7. Attach the keyboard stand [A] on the keyboard stand bracket ( x4).
8. Place a keyboard on the keyboard stand, and then pass the keyboard cable through the
hole in the keyboard stand.
9. Remove the rear cover [A].
2. Installation
272
