Ricoh MP C2504 - Page 475

To Next Page

To Previous Page

4. Connecting part (rear) [A] ( x 3).

5. Separate PCU [A] and development unit [B].

• When holding the development unit, be sure to obey the following three DO NOTs:

4. Replacement and Adjustment

466
