SC No. Type Error Name/Error Condition/Major Cause/Solution

Check if the SC occurs by turning the power OFF then ON. If the SC

occurs again, do the following steps. Check if the SC reoccurs by cycling

the power after each step.

1. Reconnect the following connectors;

• Scanner Carriage - IPU harness (FFC)

• SBU - LEDB harness (FFC)

• IPU- BCU harness

2. Check the white reference seal that attached back of sheet-through

exposure glass. Replace the sheet-through exposure glass, if dirty or

damaged.

3. Replace the Scanner Carriage.

4. Replace the IPU.

5. Replace the following harnesses;

• Scanner Carriage - IPU harness (FFC)

• IPU - BCU harness

6. Replace the BCU.

6. Troubleshooting

772
