Ricoh MP C2504 User Manual

SC No. Type Error Name/Error Condition/Major Cause/Solution
SC102-00 D LED Illumination Adjustment Error
The white level peak reached the prescribed threshold when the white
plate was scanned after a specified number of adjustments.
• LED defective
• IDB (LED driver) defective
• SBU defective
• IPU defective
• Power/signal harness defective
Check if the SC occurs by turning the power OFF then ON. If the SC
occurs again, do the following steps. Check if the SC reoccurs by cycling
the power after each step.
1. Reconnect the power/signal harness.
2. Replace the following parts:
• Replace the Scanner Carriage.
• Replace the IPU board.
• Replace the power/signal harness.
Service Call 101-195
773

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
