ST STM32L4x6 User Manual

Comparator (COMP) RM0351
588/1693 DocID024597 Rev 3
19.6.3 COMP register map
The following table summarizes the comparator registers.
Refer to Section 2.2.2 on page 67 for the register boundary addresses.
Table 115. COMP register map and reset values
Offset Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
COMP1_CSR
LOCK
VALUE
Res. Res. Res. Res. Res. Res.
SCALEN
BRGEN.
Res.
BLANKING
HYST
POLARITY.
Res. Res. Res. Res. Res. Res. Res.
INPSEL.
INMSEL
PWRMODE
Res.
EN
Reset value 00 00 000000 000000 0
0x04
COMP2_CSR
LOCK
VALUE
Res. Res. Res. Res. Res. Res.
SCALEN.
BRGEN.
Res.
BLANKING
HYST.
POLARITY.
Res. Res. Res. Res. Res.
WINMODE
Res.
INPSEL
INMSEL
PWRMODE
Res.
EN
Reset value 00 00 000000 0 000000 0
