ST STM32L4x6 User Manual

DocID024597 Rev 3 843/1693
RM0351 Advanced-control timers (TIM1/TIM8)
856
26.4.23 TIM1/TIM8 capture/compare mode register 3 (TIMx_CCMR3)
Address offset: 0x54
Reset value: 0x0000 0000
Refer to the above CCMR1 register description. Channels 5 and 6 can only be configured in
output.
Output compare mode
26.4.24 TIM1/TIM8 capture/compare register 5 (TIMx_CCR5)
Address offset: 0x58
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. OC6M[3] Res. Res. Res. Res. Res. Res. Res. OC5M[3]
rw rw
1514131211109 8 7654321 0
OC6
CE
OC6M[2:0]
OC6
PE
OC6FE Res. Res.
OC5
CE.
OC5M[2:0] OC5PE OC5FE Res. Res.
rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:25 Reserved, must be kept at reset value.
Bit 24 OC6M[3]: Output Compare 6 mode - bit 3
Bits 23:17 Reserved, must be kept at reset value.
Bit 16 OC5M[3]: Output Compare 5 mode - bit 3
Bit 15 OC6CE: Output compare 6 clear enable
Bits 14:12 OC6M: Output compare 6 mode
Bit 11 OC6PE: Output compare 6 preload enable
Bit 10 OC6FE: Output compare 6 fast enable
Bits 9:8 Reserved, must be kept at reset value.
Bit 7 OC5CE: Output compare 5 clear enable
Bits 6:4 OC5M: Output compare 5 mode
Bit 3 OC5PE: Output compare 5 preload enable
Bit 2 OC5FE: Output compare 5 fast enable
Bits 1:0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
GC5C3 GC5C2 GC5C1 Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
rw rw rw
1514131211109876543210
CCR5[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
