Touch sensing controller (TSC) RM0351
706/1693 DocID024597 Rev 3
23.6.8 TSC I/O channel control register (TSC_IOCCRTSC_IOCCR)
Address offset: 0x28
Reset value: 0x0000 0000
23.6.9 TSC I/O group control status register (TSC_IOGCSR)
Address offset: 0x30
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
G8_IO4 G8_IO3 G8_IO2 G8_IO1 G7_IO4 G7_IO3 G7_IO2 G7_IO1 G6_IO4 G6_IO3 G6_IO2 G6_IO1 G5_IO4 G5_IO3 G5_IO2 G5_IO1
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
G4_IO4 G4_IO3 G4_IO2 G4_IO1 G3_IO4 G3_IO3 G3_IO2 G3_IO1 G2_IO4 G2_IO3 G2_IO2 G2_IO1 G1_IO4 G1_IO3 G1_IO2 G1_IO1
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 Gx_IOy: Gx_IOy channel mode
These bits are set and cleared by software to configure the Gx_IOy as a channel I/O.
0: Gx_IOy unused
1: Gx_IOy used as channel
Note: These bits must not be modified when an acquisition is ongoing.
During the acquisition phase and even if the TSC peripheral alternate function is not
enabled, as soon as the TSC_IOCCR bit is set, the corresponding GPIO analog switch
is automatically controlled by the touch sensing controller.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. G8S G7S G6S G5S G4S G3S G2S G1S
rrrrrrrr
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. G8E G7E G6E G5E G4E G3E G2E G1E
rw rw rw rw rw rw rw rw
Bits 31:24 Reserved, must be kept at reset value.
