RM0351 Liquid crystal display controller (LCD)

690

22.6 LCD registers

The peripheral registers have to be accessed by words (32-bit).

22.6.1 LCD control register (LCD_CR)

Address offset: 0x00

Reset value: 0x0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.

1514131211109876543210

Res. Res. Res. Res. Res. Res. Res. BUFEN

MUX_

SEG

BIAS[1:0] DUTY[2:0] VSEL LCDEN

rw rw rw rw rw rw rw rw rw

Bits 31:9 Reserved, must be kept at reset value

Bit 8 BUFEN: Voltage output buffer enable

This bit is used to enable/disable the voltage output buffer for higher driving capability.

0: Output buffer disabled

1: Output buffer enabled

Bit 7 MUX_SEG: Mux segment enable

This bit is used to enable SEG pin remapping. Four SEG pins can be multiplexed with

SEG[31:28]. See Section 22.3.7.

0: SEG pin multiplexing disabled

1: SEG[31:28] are multiplexed with SEG[43:40]

Bits 6:5 BIAS[1:0]: Bias selector

These bits determine the bias used. Value 11 is forbidden.

00: Bias 1/4

01: Bias 1/2

10: Bias 1/3

11: Reserved
