ST STM32L4x6 User Manual

DocID024597 Rev 3 113/1693
RM0351 Embedded Flash memory (FLASH)
120
3.7.8 Flash option register (FLASH_OPTR)
Address offset: 0x20
Reset value: 0xFXXX XXXX. The option bits are loaded with values from Flash memory at
reset release.
Access: no wait state when no Flash memory operation is on going, word, half-word and
byte access
Bit 24 ECCIE: ECC correction interrupt enable
0: ECCC interrupt disabled
1: ECCC interrupt enabled
Bits 23:21 Reserved, must be kept at reset value.
Bit 20 SYSF_ECC: System Flash ECC fail
This bit indicates that the ECC error correction or double ECC error detection is
located in the System Flash.
Bit 19 BK_ECC: ECC fail bank
This bit indicates which bank is concerned by the ECC error correction or by the
double ECC error detection.
0: bank 1
1: bank 2
Bits 18:0 ADDR_ECC: ECC fail address
This bit indicates which address in the bank is concerned by the ECC error
correction or by the double ECC error detection.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res.
SRAM2
_RST
SRAM2
_PE
nBOOT
1
Res.
DUAL
BANK
BFB2
WWDG
_SW
IWGD_
STDBY
IWDG_
StOP
IWDG_
SW
rw rw rw rw rw rw rw rw rw
1514131211109876543210
Res.
nRST_
SHDW
nRST_
STDBY
nRST_
STOP
Res. BOR_LEV[2:0] RDP[7:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:26 Reserved, must be kept at reset value.
Bit 25 SRAM2_RST: SRAM2 Erase when system reset
0: SRAM2 erased when a system reset occurs
1: SRAM2 is not erased when a system reset occurs
Bit 24 SRAM2_PE: SRAM2 parity check enable
0: SRAM2 parity check enable
1: SRAM2 parity check disable
Bit 23 nBOOT1: Boot configuration
Together with the BOOT0 pin, this bit selects boot mode from the Flash main
memory, SRAM1 or the System memory. Refer to Section 2.6: Boot
configuration.
Bit 22 Reserved, must be kept at reset value.
