Reset and clock control (RCC) RM0351
246/1693 DocID024597 Rev 3
6.4.29 Backup domain control register (RCC_BDCR)
Address offset: 0x90
Reset value: 0x0000 0000, reset by Backup domain Reset, except LSCOSEL, LSCOEN
and BDRST which are reset only by Backup domain power-on reset.
Access: 0 ≤wait state ≤3, word, half-word and byte access
Wait states are inserted in case of successive accesses to this register.
Note: The bits of the Backup domain control register (RCC_BDCR) are outside of the V
CORE
domain. As a result, after Reset, these bits are write-protected and the DBP bit in the
Section 5.4.1: Power control register 1 (PWR_CR1) has to be set before these can be
modified. Refer to Section 5.1.5: Battery backup domain on page 136 for further
information. These bits (except LSCOSEL, LSCOEN and BDRST) are only reset after a
Backup domain Reset (see Section 6.1.3: Backup domain reset). Any internal or external
Reset will not have any effect on these bits.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res.
LSCO
SEL
LSCO
EN
Res. Res. Res. Res. Res. Res. Res. BDRST
rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RTC
EN
Res. Res. Res. Res. Res. RTCSEL[1:0] Res.
LSE
CSSD
LSE
CSSON
LSEDRV[1:0]
LSE
BYP
LSE
RDY
LSEON
rw rw rw r rw rw rw rw r rw
Bits 31:26 Reserved, must be kept at reset value.
Bit 25 LSCOSEL: Low speed clock output selection
Set and cleared by software.
0: LSI clock selected
1: LSE clock selected
Bit 24 LSCOEN: Low speed clock output enable
Set and cleared by software.
0: Low speed clock output (LSCO) disable
1: Low speed clock output (LSCO) enable
Bits 23:17 Reserved, must be kept at reset value.
Bit 16 BDRST: Backup domain software reset
Set and cleared by software.
0: Reset not activated
1: Resets the entire Backup domain
Bit 15 RTCEN: RTC clock enable
Set and cleared by software.
0: RTC clock disabled
1: RTC clock enabled
Bits 14:10 Reserved, must be kept at reset value.
