Digital filter for sigma delta modulators (DFSDM) RM0351
638/1693 DocID024597 Rev 3
21.7.3 DFSDM interrupt and status register (DFSDMx_ISR)
Address offset: 0x100 * (x+1) + 0x008, x = 0...3
Reset value: 0x00FF 0000
Bit 5 SCDIE: Short-circuit detector interrupt enable
0: short-circuit detector interrupt is disabled
1: short-circuit detector interrupt is enabled
Please see the explanation of SCDF[7:0] in DFSDMx_ISR.
Note: SCDIE is present only in DFSDM0_CR2 register (filter x=0)
Bit 4 AWDIE: Analog watchdog interrupt enable
0: Analog watchdog interrupt is disabled
1: Analog watchdog interrupt is enabled
Please see the explanation of AWDF in DFSDMx_ISR.
Bit 3 ROVRIE: Regular data overrun interrupt enable
0: Regular data overrun interrupt is disabled
1: Regular data overrun interrupt is enabled
Please see the explanation of ROVRF in DFSDMx_ISR.
Bit 2 JOVRIE: Injected data overrun interrupt enable
0: Injected data overrun interrupt is disabled
1: Injected data overrun interrupt is enabled
Please see the explanation of JOVRF in DFSDMx_ISR.
Bit 1 REOCIE: Regular end of conversion interrupt enable
0: Regular end of conversion interrupt is disabled
1: Regular end of conversion interrupt is enabled
Please see the explanation of REOCF in DFSDMx_ISR.
Bit 0 JEOCIE: Injected end of conversion interrupt enable
0: Injected end of conversion interrupt is disabled
1: Injected end of conversion interrupt is enabled
Please see the explanation of JEOCF in DFSDMx_ISR.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
SCDF[7:0] CKABF[7:0]
rrrrrrrrrrrrrrrr
1514131211109876543210
Res. RCIP JCIP Res. Res. Res. Res. Res. Res. Res. Res. AWDF ROVRF JOVRF REOCF JEOCF
rr rrrrr
