ST STM32L4x6 User Manual

DocID024597 Rev 3 347/1693
RM0351 Flexible static memory controller (FSMC)
399
Figure 30. FMC memory banks
14.4.1 NOR/PSRAM address mapping
HADDR[27:26] bits are used to select one of the four memory banks as shown in Table 46.
The HADDR[25:0] bits contain the external memory address. Since HADDR is a byte
address whereas the memory is addressed at word level, the address actually issued to the
memory varies according to the memory data width, as shown in the following table.
D^ϯϰϰϳϱsϭ
ĂŶŬϭ
ϰdžϲϰD
EKZW^ZD^ZD
^ƵƉƉŽƌƚĞĚŵĞŵŽƌLJƚLJƉĞ
ĂŶŬ
ϬdžϲϬϬϬϬϬϬϬ
ĚĚƌĞƐƐ
Ϭdžϲ&&&&&&&
ϬdžϳϬϬϬϬϬϬϬ
Ϭdžϳ&&&&&&&
ϬdžϴϬϬϬϬϬϬϬ
Ϭdžϴ&&&&&&&
ϬdžϵϬϬϬϬϬϬϬ
Ϭdžϵ&&&&&&&
ZĞƐĞƌǀĞĚ
ĂŶŬϯ
ϰdžϲϰD
ZĞƐĞƌǀĞĚ
EE&ůĂƐŚŵĞŵŽƌLJ
Table 46. NOR/PSRAM bank selection
HADDR[27:26]
(1)
1. HADDR are internal AHB address lines that are translated to external memory.
Selected bank
00 Bank 1 - NOR/PSRAM 1
01 Bank 1 - NOR/PSRAM 2
10 Bank 1 - NOR/PSRAM 3
11 Bank 1 - NOR/PSRAM 4
Table 47. NOR/PSRAM External memory address
Memory width
(1)
Data address issued to the memory Maximum memory capacity (bits)
8-bit HADDR[25:0] 64 Mbytes x 8 = 512 Mbit
16-bit HADDR[25:1] >> 1 64 Mbytes/2 x 16 = 512 Mbit
