ST STM32L4x6 User Manual

DocID024597 Rev 3 833/1693
RM0351 Advanced-control timers (TIM1/TIM8)
856
26.4.10 TIM1/TIM8 counter (TIMx_CNT)
Address offset: 0x24
Reset value: 0x0000 0000
26.4.11 TIM1/TIM8 prescaler (TIMx_PSC)
Address offset: 0x28
Reset value: 0x0000
26.4.12 TIM1/TIM8 auto-reload register (TIMx_ARR)
Address offset: 0x2C
Reset value: 0xFFFF
31 30 29 28 27 26 25 24 23 22 21 20
19 18 17 16
UIFCPY Res. Res. Res. Res. Res. Res. Res. Re s. Res. Res. Res. Res. Res. Res. Res.
r
1514131211109876543210
CNT[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bit 31 UIFCPY: UIF copy
This bit is a read-only copy of the UIF bit of the TIMx_ISR register. If the UIFREMAP bit in the
TIMxCR1 is reset, bit 31 is reserved and read at 0.
Bits 30:16 Reserved, must be kept at reset value.
Bits 15:0 CNT[15:0]: Counter value
1514131211109876543210
PSC[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 15:0 PSC[15:0]: Prescaler value
The counter clock frequency (CK_CNT) is equal to f
CK_PSC
/ (PSC[15:0] + 1).
PSC contains the value to be loaded in the active prescaler register at each update event
(including when the counter is cleared through UG bit of TIMx_EGR register or through trigger
controller when configured in “reset mode”).
1514131211109876543210
ARR[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 15:0 ARR[15:0]: Prescaler value
ARR is the value to be loaded in the actual auto-reload register.
Refer to the Section 26.3.1: Time-base unit on page 754 for more details about ARR update
and behavior.
The counter is blocked while the auto-reload value is null.
