DocID024597 Rev 3 529/1693
RM0351 Analog-to-digital converters (ADC)
540
16.5.20 ADC Analog Watchdog 3 Configuration Register (ADCx_AWD3CR)
Address offset: 0xA4
Reset value: 0x0000 0000
16.5.21 ADC Differential Mode Selection Register (ADCx_DIFSEL)
Address offset: 0xB0
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. AWD3CH[18:16]
1514131211109876543210
AWD3CH[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:19 Reserved, must be kept at reset value.
Bits 18:0 AWD2CH[18:0]: Analog watchdog 2 channel selection
These bits are set and cleared by software. They enable and select the input channels to be guarded
by the analog watchdog 2.
AWD2CH[i] = 0: ADC analog input channel-i is not monitored by AWD2
AWD2CH[i] = 1: ADC analog input channel-i is monitored by AWD2
When AWD2CH[18:0] = 000..0, the analog Watchdog 2 is disabled
Note: The channels selected by AWD2CH must be also selected into the SQRi or JSQRi registers.
Software is allowed to write these bits only when ADSTART=0 and JADSTART=0 (which
ensures that no conversion is ongoing).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. DIFSEL[18:16]
rrr
1514131211109876543210
DIFSEL[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw r
