General-purpose timers (TIM15/16/17) RM0351
1006/1693 DocID024597 Rev 3
28.6.19 TIM17 option register 2 (TIM17_OR2)
Address offset: 0x60
Reset value: 0x0000 0001
Bits 31:2 Reserved, must be kept at reset value.
Bits1:0 TI1_RMP[1:0]: Input capture 1 remap
00: TIM17 input capture 1 is connected to I/O
01: TIM17 input capture 1 is connected to MSI
10: TIM17 input capture 1 is connected to HSE/32
11: TIM17 input capture 1 is connected to MCO
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res Res
1514131211109876543210
Res Res Res Res
BKCM
P2P
BKCM
P1P
BKINP
BKDF
BK2E
Res Res Res Res Res
BKCM
P2E
BKCM
P1E
BKINE
rw rw rw rw rw rw rw
Bits 31:12 Reserved, must be kept at reset value.
Bit 11 BKCMP2P: BRK COMP2 input polarity
This bit selects the COMP2 input sensitivity. It must be programmed together with the BKP
polarity bit.
0: COMP2 input is active low
1: COMP2 input is active high
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Bit 10 BKCMP1P: BRK COMP1 input polarity
This bit selects the COMP1 input sensitivity. It must be programmed together with the BKP
polarity bit.
0: COMP1 input is active low
1: COMP1 input is active high
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Bit 9 BKINP: BRK BKIN input polarity
This bit selects the BKIN alternate function input sensitivity. It must be programmed together
with the BKP polarity bit.
0: BKIN input is active low
1: BKIN input is active high
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
