Page #510 background image
Analog-to-digital converters (ADC) RM0351
510/1693 DocID024597 Rev 3
16.5.4 ADC configuration register (ADCx_CFGR)
Address offset: 0x0C
Reset value: 0x8000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
JQDIS AWD1CH[4:0] JAUTO
JAWD1
EN
AWD1
EN
AWD1S
GL
JQM
JDISC
EN
DISCNUM[2:0]
DISC
EN
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
1514131211109876543210
Res.
AUT
DLY
CONT
OVR
MOD
EXTEN[1:0] EXTSEL[3:0] ALIGN RES[1:0] Res.
DMA
CFG
DMA
EN
rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bit 31 JQDIS: Injected Queue disable
These bits are set and cleared by software to disable the Injected Queue mechanism :
0: Injected Queue enabled
1: Injected Queue disabled
Note: Software is allowed to write this bit only when ADSTART=0 and JADSTART=0 (which ensures
that no regular nor injected conversion is ongoing).
A set or reset of JQDIS bit causes the injected queue to be flushed and the JSQR register is
cleared.
Bits 30:26 AWD1CH[4:0]: Analog watchdog 1 channel selection
These bits are set and cleared by software. They select the input channel to be guarded by the
analog watchdog.
00000: ADC analog input channel-0 monitored by AWD1 (available on ADC1 only)
00001: ADC analog input channel-1 monitored by AWD1
.....
10010: ADC analog input channel-18 monitored by AWD1
others: reserved, must not be used
Note: The channel selected by AWD1CH must be also selected into the SQRi or JSQRi registers.
Software is allowed to write these bits only when ADSTART=0 and JADSTART=0 (which
ensures that no conversion is ongoing).
Bit 25 JAUTO: Automatic injected group conversion
This bit is set and cleared by software to enable/disable automatic injected group conversion after
regular group conversion.
0: Automatic injected group conversion disabled
1: Automatic injected group conversion enabled
Note: Software is allowed to write this bit only when ADSTART=0 and JADSTART=0 (which ensures
that no regular nor injected conversion is ongoing).
When dual mode is enabled (DUAL bits in ADCx_CCR register are not equal to zero), the bit
JAUTO of the slave ADC is no more writable and its content is equal to the bit JAUTO of the
master ADC.
Bit 24 JAWD1EN: Analog watchdog 1 enable on injected channels
This bit is set and cleared by software
0: Analog watchdog 1 disabled on injected channels
1: Analog watchdog 1 enabled on injected channels
Note: Software is allowed to write this bit only when JADSTART=0 (which ensures that no injected
conversion is ongoing).
