DocID024597 Rev 3 193/1693
RM0351 Reset and clock control (RCC)
253
The input capture channel of the Timer 15 can be a GPIO line or an internal clock of the
MCU. This selection is performed through the TI1_RMP bit in the TIM15_OR register. The
possibilities are the following ones:
• TIM15 Channel1 is connected to the GPIO. Refer to the alternate function mapping in
the device datasheets.
• TIM15 Channel1 is connected to the LSE.
Figure 15. Frequency measurement with TIM16 in capture mode
The input capture channel of the Timer 16 can be a GPIO line or an internal clock of the
MCU. This selection is performed through the TI1_RMP[1:0] bits in the TIM16_OR register.
The possibilities are the following ones:
• TIM16 Channel1 is connected to the GPIO. Refer to the alternate function mapping in
the device datasheets.
• TIM16 Channel1 is connected to the LSI clock.
• TIM16 Channel1 is connected to the LSE clock.
• TIM16 Channel1 is connected to the RTC wakeup interrupt signal. In this case the RTC
interrupt should be enabled.
Figure 16. Frequency measurement with TIM17 in capture mode
069
7,0
7,
7,B503>@
*3,2
/6(
/6,
57&ZDNHXSLQWHUUXSW
069
7,0
7,
7,B503>@
*3,2
+6(
06,
0&2
