ST STM32L4x6 User Manual

DocID024597 Rev 3 747/1693
RM0351 Advanced encryption standard hardware accelerator (AES)
751
25.14.14 AES key register 5 (AES_KEYR5) (key[191:160])
Address offset: 0x34
Reset value: 0x0000 0000
25.14.15 AES key register 6 (AES_KEYR6) (key[223:192])
Address offset: 0x38
Reset value: 0x0000 0000
25.14.16 AES key register 7 (AES_KEYR7) (MSB: key[255:224])
Address offset: 0x3C
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
KEYR431:16]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
KEYR4[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 KEYR4[31:0]: Data output register (key [159:128])
Same description as AES_KEYR0 for the key[159:128].
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
KEYR5[31:16]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
KEYR5[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 KEYR5[31:0]: Data output register (key [191:160])
Same description as AES_KEYR0 for the key[191:160].
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
KEYR631:16]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
KEYR615:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:0 KEYR6[31:0]: Data output register (key [223:192])
Same description as AES_KEYR0 for the key[223:192].
