RM0351 Reset and clock control (RCC)
253
6.4.17 AHB2 peripheral clock enable register (RCC_AHB2ENR)
Address offset: 0x4C
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access
Note: When the peripheral clock is not active, the peripheral registers read or write access is not
supported.
Bits 31:17 Reserved, must be kept at reset value.
Bit 16 TSCEN: Touch Sensing Controller clock enable
Set and cleared by software.
0: TSC clock disable
1: TSC clock enable
Bits 15:13 Reserved, must be kept at reset value.
Bit 12 CRCEN: CRC clock enable
Set and cleared by software.
0: CRC clock disable
1: CRC clock enable
Bits 11:9 Reserved, must be kept at reset value.
Bit 8 FLASHEN: Flash memory interface clock enable
Set and cleared by software. This bit can be disabled only when the Flash is in power down
mode.
0: Flash memory interface clock disable
1: Flash memory interface clock enable
Bits 7:2 Reserved, must be kept at reset value.
Bit 1 DMA2EN: DMA2 clock enable
Set and cleared by software.
0: DMA2 clock disable
1: DMA2 clock enable
Bit 0 DMA1EN: DMA1 clock enable
Set and cleared by software.
0: DMA1 clock disable
1: DMA1 clock enable
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
RNG
EN
Res. AESEN
rw rw
1514131211109876543210
Res. Res. ADCEN
OTGFS
EN
Res. Res. Res. Res.
GPIOH
EN
GPIOG
EN
GPIOF
EN
GPIOE
EN
GPIOD
EN
GPIOC
EN
GPIOB
EN
GPIOA
EN
rw rw rw rw rw rw rw rw rw rw
