Analog-to-digital converters (ADC) RM0351
514/1693 DocID024597 Rev 3
16.5.5 ADC configuration register 2 (ADCx_CFGR2)
Address offset: 0x10
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res.
ROV
SM
TROVS OVSS[3:0] OVSR[2:0] JOVSE ROVSE
rw rw rw rw rw rw rw rw rw rw rw
Bits 31:11 Reserved, must be kept at reset value.
Bit 10 ROVSM: Regular Oversampling mode
This bit is set and cleared by software to select the regular oversampling mode.
0: Continued mode: When injected conversions are triggered, the oversampling is temporary
stopped and continued after the injection sequence (oversampling buffer is maintained during
injected sequence)
1: Resumed mode: When injected conversions are triggered, the current oversampling is aborted
and resumed from start after the injection sequence (oversampling buffer is zeroed by injected
sequence start)
Note: Software is allowed to write this bit only when ADSTART=0 (which ensures that no conversion
is ongoing).
Bit 9 TROVS: Triggered Regular Oversampling
This bit is set and cleared by software to enable triggered oversampling
0: All oversampled conversions for a channel are done consecutively following a trigger
1: Each oversampled conversion for a channel needs a new trigger
Note: Software is allowed to write this bit only when ADSTART=0 (which ensures that no conversion
is ongoing).
Bits 8:5 OVSS[3:0]: Oversampling shift
This bitfield is set and cleared by software to define the right shifting applied to the raw oversampling
result.
0000: No shift
0001: Shift 1-bit
0010: Shift 2-bits
0011: Shift 3-bits
0100: Shift 4-bits
0101: Shift 5-bits
0110: Shift 6-bits
0111: Shift 7-bits
1000: Shift 8-bits
Other codes reserved
Note: Software is allowed to write these bits only when ADSTART=0 (which ensures that no
conversion is ongoing).
