Embedded Flash memory (FLASH) RM0351
80/1693 DocID024597 Rev 3
Information block
Bank 1 0x1FFF 0000 - 0x1FFF 6FFF 28 K
System memory
Bank 2 0x1FFF 8000 - 0x1FFF EFFF 28 K
Bank 1 0x1FFF 7000 - 0x1FFF 73FF 1 K OTP area
Bank 1 0x1FFF 7800 - 0x1FFF 780F 16
Option bytes
Bank 2 0x1FFF F800 - 0x1FFF F80F 16
Table 5. Flash module - 1 MB dual bank organization (continued)
Flash area Flash memory addresses
Size
(bytes)
Name
Table 6. Flash module - 512 KB dual bank organization
(1)
Flash area Flash memory addresses
Size
(bytes)
Name
Main memory
Bank 1
0x0800 0000 - 0x0800 07FF 2 K Page 0
0x0800 0800 - 0x0800 0FFF 2 K Page 1
0x0800 1000 - 0x0800 17FF 2 K Page 2
0x0800 1800 - 0x0800 1FFF 2 K Page 3
-
-
-
-
-
-
-
-
-
-
-
-
0x0803 F800 - 0x0803 FFFF 2 K Page 127
Bank 2
0x0804 0000 - 0x0804 07FF 2 K Page 256
0x0804 0800 - 0x0804 0FFF 2 K Page 257
0x0804 1000 - 0x0804 17FF 2 K Page 258
0x0804 1800 - 0x0804 1FFF 2 K Page 259
-
-
-
-
-
-
-
-
-
-
-
-
0x0807 F800 - 0x0807 FFFF 2 K Page 383
Information block
Bank 1 0x1FFF 0000 - 0x1FFF 6FFF 28 K
System memory
Bank 2 0x1FFF 8000 - 0x1FFF EFFF 28 K
Bank 1 0x1FFF 7000 - 0x1FFF 73FF 1 K OTP area
Bank 1 0x1FFF 7800 - 0x1FFF 780F 16
Option bytes
Bank 2 0x1FFF F800 - 0x1FFF F80F 16
1. For 512 KB devices, option DUALBANK=1
