Analog-to-digital converters (ADC) RM0351

530/1693 DocID024597 Rev 3

16.5.22 ADC Calibration Factors (ADCx_CALFACT)

Address offset: 0xB4

Reset value: 0x0000 0000

Bits 31:19 Reserved, must be kept at reset value.

Bits 18:16 DIFSEL[18:16]: Differential mode for channels 18 to 16.

These bits are read only. These channels are forced to single-ended input mode (either connected to

a single-ended I/O port or to an internal channel).

Bits 15:1 DIFSEL[15:1]: Differential mode for channels 15 to 1

These bits are set and cleared by software. They allow to select if a channel is configured as single

ended or differential mode.

DIFSEL[i] = 0: ADC analog input channel-i is configured in single ended mode

DIFSEL[i] = 1: ADC analog input channel-i is configured in differential mode

Note: Software is allowed to write these bits only when the ADC is disabled (ADCAL=0,

JADSTART=0, JADSTP=0, ADSTART=0, ADSTP=0, ADDIS=0 and ADEN=0).

It is mandatory to keep cleared ADC1_DIFSEL[15] (connected to an internal single ended

channel)

Bit 0 DIFSEL[0]: Differential mode for channel 0

This bit is read only. This channel is forced to single-ended input mode (connected to an internal

channel).

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Res. Res. Res. Res. Res. Res. Res. Res. Res. CALFACT_D[6:0]

rw rw rw rw rw rw rw

151413121110987654321 0

Res. Res. Res. Res. Res. Res. Res. Res. Res. CALFACT_S[6:0]

rw rw rw rw rw rw rw

Bits 31:23 Reserved, must be kept at reset value.
