Analog-to-digital converters (ADC) RM0351

450/1693 DocID024597 Rev 3

16.3.19 Injected channel management

Triggered injection mode

To use triggered injection, the JAUTO bit in the ADCx_CFGR register must be cleared.

1. Start the conversion of a group of regular channels either by an external trigger or by

setting the ADSTART bit in the ADCx_CR register.

2. If an external injected trigger occurs, or if the JADSTART bit in the ADCx_CR register is

set during the conversion of a regular group of channels, the current conversion is

EXT10 TIM1_TRGO2 event Internal signal from on-chip timers 1010

EXT11 TIM2_TRGO event Internal signal from on-chip timers 1011

EXT12 TIM4_TRGO event Internal signal from on-chip timers 1100

EXT13 TIM6_TRGO event Internal signal from on-chip timers 1101

EXT14 TIM15_TRGO event Internal signal from on-chip timers 1110

EXT15 TIM3_CC4 event Internal signal from on-chip timers 1111

Table 88. ADC1, ADC2 and ADC3 - External triggers for regular channels (continued)

Name Source Type EXTSEL[3:0]

Table 89. ADC1, ADC2 and ADC3 - External trigger for injected channels

Name Source Type JEXTSEL[3..0]

JEXT0 TIM1_TRGO event Internal signal from on-chip timers 0000

JEXT1 TIM1_CC4 event Internal signal from on-chip timers 0001

JEXT2 TIM2_TRGO event Internal signal from on-chip timers 0010

JEXT3 TIM2_CC1 event Internal signal from on-chip timers 0011

JEXT4 TIM3_CC4 event Internal signal from on-chip timers 0100

JEXT5 TIM4_TRGO event Internal signal from on-chip timers 0101

JEXT6 EXTI line 15 External pin 0110

JEXT7 TIM8_CC4 event Internal signal from on-chip timers 0111

JEXT8 TIM1_TRGO2 event Internal signal from on-chip timers 1000

JEXT9 TIM8_TRGO event Internal signal from on-chip timers 1001

JEXT10 TIM8_TRGO2 event Internal signal from on-chip timers 1010

JEXT11 TIM3_CC3 event Internal signal from on-chip timers 1011

JEXT12 TIM3_TRGO event Internal signal from on-chip timers 1100

JEXT13 TIM3_CC1 event Internal signal from on-chip timers 1101

JEXT14 TIM6_TRGO event Internal signal from on-chip timers 1110

JEXT15 TIM15_TRGO event Internal signal from on-chip timers 1111
