Note: DMA may be used to read the data from this register. Half-word accesses may be used to
read only the MSBs of conversion data.
Reading this register also clears JEOCF in DFSDMx_ISR. Thus, the firmware must not read
this register if DMA is activated to read data from this register.
21.7.8 DFSDM data register for the regular channel (DFSDMx_RDATAR)
Address offset: 0x100 * (x+1) + 0x01C, x = 0...3
Reset value: 0x0000 0000
Note: Half-word accesses may be used to read only the MSBs of conversion data.
Reading this register also clears REOCF in DFSDMx_ISR.
Bits 31:8 JDATA[23:0]: Injected group conversion data
When each conversion of a channel in the injected group finishes, its resulting data is stored in this
field. The data is valid when JEOCF=1. Reading this register clears the corresponding JEOCF.
Bits 7:3 Reserved, must be kept at reset value.
Bits 2:0 JDATACH[2:0]: Injected channel most recently converted
When each conversion of a channel in the injected group finishes, JDATACH[2:0] is updated to
indicate which channel was converted. Thus, JDATA[23:0] holds the data that corresponds to the
channel indicated by JDATACH[2:0].
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RDATA[23:8]
1514131211109876543210
RDATA[7:0] Res. Res. Res. RPEND Res. RDATACH[2:0]
rrrrrrrr r rrr
Bits 31:8 RDATA[23:0]: Regular channel conversion data
When each regular conversion finishes, its data is stored in this register. The data is valid when
REOCF=1. Reading this register clears the corresponding REOCF.
Bits 7:5 Reserved, must be kept at reset value.
Bit 4 RPEND: Regular channel pending data
Regular data in RDATA[23:0] was delayed due to an injected channel trigger during the conversion
Bit 3 Reserved, must be kept at reset value.
Bits 2:0 RDATACH[2:0]: Regular channel most recently converted
When each regular conversion finishes, RDATACH[2:0] is updated to indicate which channel was
converted (because regular channel selection RCH[2:0] in DFSDMx_CR1 register can be updated
during regular conversion). Thus RDATA[23:0] holds the data that corresponds to the channel
indicated by RDATACH[2:0].
