ST STM32L4x6 User Manual

DocID024597 Rev 3 1169/1693
RM0351 Inter-integrated circuit (I2C) interface
1177
35.7.5 Timing register (I2C_TIMINGR)
Address offset: 0x10
Reset value: 0x0000 0000
Access: No wait states
Note: This register must be configured when the I2C is disabled (PE = 0).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
PRESC[3:0] Res. Res. Res. Res. SCLDEL[3:0] SDADEL[3:0]
rw rw rw
15141312111098 7 654321 0
SCLH[7:0] SCLL[7:0]
rw rw
Bits 31:28 PRESC[3:0]: Timing prescaler
This field is used to prescale I2CCLK in order to generate the clock period t
PRESC
used for data
setup and hold counters (refer to I2C timings on page 1113) and for SCL high and low level
counters (refer to I2C master initialization on page 1128).
t
PRESC
= (PRESC+1) x t
I2CCLK
Bits 27:24 Reserved, must be kept at reset value.
Bits 23:20 SCLDEL[3:0]: Data setup time
This field is used to generate a delay t
SCLDEL
between SDA edge and SCL rising edge. In
master mode and in slave mode with NOSTRETCH = 0, the SCL line is stretched low during
t
SCLDEL
.
t
SCLDEL
= (SCLDEL+1) x t
PRESC
Note: t
SCLDEL
is used to generate t
SU:DAT
timing.
Bits 19:16 SDADEL[3:0]: Data hold time
This field is used to generate the delay t
SDADEL
between SCL falling edge and SDA edge. In
master mode and in slave mode with NOSTRETCH = 0, the SCL line is stretched low during
t
SDADEL
.
t
SDADEL
= SDADEL x t
PRESC
Note: SDADEL is used to generate t
HD:DAT
timing.
Bits 15:8 SCLH[7:0]: SCL high period (master mode)
This field is used to generate the SCL high period in master mode.
t
SCLH
= (SCLH+1) x t
PRESC
Note: SCLH is also used to generate t
SU:STO
and t
HD:STA
timing.
Bits 7:0 SCLL[7:0]: SCL low period (master mode)
This field is used to generate the SCL low period in master mode.
t
SCLL
= (SCLL+1) x t
PRESC
Note: SCLL is also used to generate t
BUF
and t
SU:STA
timings.
