DocID024597 Rev 3 567/1693
RM0351 Digital-to-analog converter (DAC)
573
17.5.14 DAC status register (DAC_SR)
Address offset: 0x34
Reset value: 0x0000 0000
Bits 31:12 Reserved, must be kept at reset value.
Bits 11:0 DACC2DOR[11:0]: DAC channel2 data output
These bits are read-only, they contain data output for DAC channel2.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
BWST2
CAL_
FLAG2
DMAU
DR2
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
rrrc_w1
1514131211109876543210
BWST1
CAL_
FLAG1
DMAU
DR1
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
rrrc_w1
Bit 31 BWST2: DAC Channel 2 busy writing sample time flag
This bit is systematically set just after Sample & Hold mode enable and is set each time the
software writes the register DAC_SHSR2 , It is cleared by hardware when the write operation
of DAC_SHSR2 is complete. ( It takes about 3 LSI periods of synchronization).
0:There is no write operation of DAC_SHSR2 ongoing : DAC_SHSR2 can be written
1:There is a write operation of DAC_SHSR2 ongoing : DAC_SHSR2 cannot be written
Bit 30 CAL_FLAG2: DAC Channel 2 calibration offset status
This bit is set and cleared by hardware
0: calibration trimming value is greater than the offset correction value
1: calibration trimming value is lower than the offset correction value
Bit 29 DMAUDR2: DAC channel2 DMA underrun flag
This bit is set by hardware and cleared by software (by writing it to 1).
0: No DMA underrun error condition occurred for DAC channel2
1: DMA underrun error condition occurred for DAC channel2 (the currently selected trigger is
driving DAC channel2 conversion at a frequency higher than the DMA service capability rate)
Bits 28:16 Reserved, must be kept at reset value.
Bit 15 BWST1: DAC Channel 1 busy writing sample time flag
This bit is systematically set just after Sample & Hold mode enable and is set each time the
software writes the register DAC_SHSR1 , It is cleared by hardware when the write operation
of DAC_SHSR1 is complete. ( It takes about 3LSI periods of synchronization).
0:There is no write operation of DAC_SHSR1 ongoing : DAC_SHSR1 can be written
1:There is a write operation of DAC_SHSR1 ongoing : DAC_SHSR1 cannot be written
