Digital filter for sigma delta modulators (DFSDM) RM0351

654/1693 DocID024597 Rev 3

0x21C

DFSDM1_

RDATAR

RDATA[23:0]

Res.

RPEND

Res.

RDATA

CH[2:0]

reset value 000000000000000000000000 0 000

0x220

DFSDM1_

AWHTR

AWHT[23:0]

Res.

BKAWH[3:0]

reset value 000000000000000000000000 0000

0x224

DFSDM1_

AWLTR

AWLT[23:0]

Res.

BKAWL[3:0]

reset value 000000000000000000000000 0000

0x228

DFSDM1_

AWSR

Res.

AWHTF[7:0] AWLTF[7:0]

reset value 0000000000000000

0x22C

DFSDM1_

AWCFR

Res.

CLRAWHTF[7:0] CLRAWLTF[7:0]

reset value 0000000000000000

0x230

DFSDM1_

EXMAX

EXMAX[23:0]

Res.

EXMAXCH[2:0]

reset value 100000000000000000000000 000

0x234

DFSDM1_

EXMIN

EXMIN[23:0]

Res.

EXMINCH[2:0]

reset value 011111111111111111111111 000

0x238

DFSDM1_

CNVTIMR

CNVCNT[27:0]

Res.

reset value 0000000000000000000000000000

0x23C -

0x2FC

Reserved

Res.

0x300

DFSDM2_

CR1

Res.

AWFSEL

FAST

Res.

RCH[2:0]

Res.

RDMAEN

Res.

RSYNC

RCONT

RSW START

Res.

JEXTEN[1:0]

Res.

JEXTSEL[2:0]

Res.

JDMAEN

JSCAN

JSYNC

Res.

JSW START

DFEN

reset value 00 000 0 000 00 000 000 00

0x304

DFSDM2_

CR2

Res.

AWDCH[7:0] EXCH[7:0]

Res.

AWDIE

ROVRIE

JOVRIE

REOCIE

JEOCIE

reset value 0000000000000000 - - 00000

0x308

DFSDM2_

ISR

Res.

RCIP

JCIP

Res.

AWDF

ROVRF

JOVRF

REOCF

JEOCF

reset value - - 00 00000

0x30C

DFSDM2_

ICR

Res.

CLR ROVRF

CLR JOVRF

Res.

reset value 00

Table 127. DFSDMx register map and reset values (continued)
