4.5.2 Peripheral Bridge 0 (AIPS-Lite 0) Memory Map

Table 4-2. Peripheral bridge 0 slot assignments

System 32-bit base address Slot

number

Module

0x4000_0000 0 —

0x4000_1000 1 —

0x4000_2000 2 —

0x4000_3000 3 —

0x4000_4000 4 —

0x4000_5000 5 —

0x4000_6000 6 —

0x4000_7000 7 —

0x4000_8000 8 DMA controller

0x4000_9000 9 DMA controller transfer control descriptors

0x4000_A000 10 —

0x4000_B000 11 —

0x4000_C000 12 FlexBus

0x4000_D000 13 —

0x4000_E000 14 —

0x4000_F000 15 —

0x4001_0000 16 —

0x4001_1000 17 —

0x4001_2000 18 —

0x4001_3000 19 —

0x4001_4000 20 —

0x4001_5000 21 —

0x4001_6000 22 —

0x4001_7000 23 —

0x4001_8000 24 —

0x4001_9000 25 —

0x4001_A000 26 —

0x4001_B000 27 —

0x4001_C000 28 —

0x4001_D000 29 —

0x4001_E000 30 —

0x4001_F000 31 Flash memory controller

0x4002_0000 32 Flash memory

0x4002_1000 33 DMA channel mutiplexer

0x4002_2000 34 —

0x4002_3000 35 —

0x4002_4000 36 —

Table continues on the next page...

Chapter 4 Memory Map

K22F Sub-Family Reference Manual, Rev. 4, 08/2016

NXP Semiconductors 145
