Table 4-2. Peripheral bridge 0 slot assignments (continued)
System 32-bit base address Slot
number
Module
0x4002_5000 37 —
0x4002_6000 38 FlexTimer (FTM) 3
0x4002_7000 39 Analog-to-digital converter (ADC) 1
0x4002_8000 40 DAC1
0x4002_9000 41 Random Number Generator (RNGA)
0x4002_A000 42 LPUART0
0x4002_B000 43 —
0x4002_C000 44 SPI 0
0x4002_D000 45 SPI 1
0x4002_E000 46 —
0x4002_F000 47 I2S 0
0x4003_0000 48 —
0x4003_1000 49 —
0x4003_2000 50 CRC
0x4003_3000 51 —
0x4003_4000 52 —
0x4003_5000 53 —
0x4003_6000 54 Programmable delay block (PDB)
0x4003_7000 55 Periodic interrupt timers (PIT)
0x4003_8000 56 FlexTimer (FTM) 0
0x4003_9000 57 FlexTimer (FTM) 1
0x4003_A000 58 FlexTimer (FTM) 2
0x4003_B000 59 Analog-to-digital converter (ADC) 0
0x4003_C000 60 —
0x4003_D000 61 Real-time clock (RTC)
0x4003_E000 62 VBAT register file
0x4003_F000 63 DAC0
0x4004_0000 64 Low-power timer (LPTMR)
0x4004_1000 65 System register file
0x4004_2000 66 —
0x4004_3000 67 —
0x4004_4000 68 —
0x4004_5000 69 —
0x4004_6000 70 —
0x4004_7000 71 SIM low-power logic
0x4004_8000 72 System integration module (SIM)
0x4004_9000 73 Port A multiplexing control
0x4004_A000 74 Port B multiplexing control
0x4004_B000 75 Port C multiplexing control
Table continues on the next page...
Peripheral bridge (AIPS-Lite) memory map
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
146 NXP Semiconductors
