NXP Semiconductors K22F series User Manual

PORT memory map (continued)
Absolute
address
(hex)
Register name
Width
(in bits)
Access Reset value
Section/
page
4004_90C0 Digital Filter Enable Register (PORTA_DFER) 32 R/W 0000_0000h 11.5.5/252
4004_90C4 Digital Filter Clock Register (PORTA_DFCR) 32 R/W 0000_0000h 11.5.6/253
4004_90C8 Digital Filter Width Register (PORTA_DFWR) 32 R/W 0000_0000h 11.5.7/253
4004_A000 Pin Control Register n (PORTB_PCR0) 32 R/W See section 11.5.1/248
4004_A004 Pin Control Register n (PORTB_PCR1) 32 R/W See section 11.5.1/248
4004_A008 Pin Control Register n (PORTB_PCR2) 32 R/W See section 11.5.1/248
4004_A00C Pin Control Register n (PORTB_PCR3) 32 R/W See section 11.5.1/248
4004_A010 Pin Control Register n (PORTB_PCR4) 32 R/W See section 11.5.1/248
4004_A014 Pin Control Register n (PORTB_PCR5) 32 R/W See section 11.5.1/248
4004_A018 Pin Control Register n (PORTB_PCR6) 32 R/W See section 11.5.1/248
4004_A01C Pin Control Register n (PORTB_PCR7) 32 R/W See section 11.5.1/248
4004_A020 Pin Control Register n (PORTB_PCR8) 32 R/W See section 11.5.1/248
4004_A024 Pin Control Register n (PORTB_PCR9) 32 R/W See section 11.5.1/248
4004_A028 Pin Control Register n (PORTB_PCR10) 32 R/W See section 11.5.1/248
4004_A02C Pin Control Register n (PORTB_PCR11) 32 R/W See section 11.5.1/248
4004_A030 Pin Control Register n (PORTB_PCR12) 32 R/W See section 11.5.1/248
4004_A034 Pin Control Register n (PORTB_PCR13) 32 R/W See section 11.5.1/248
4004_A038 Pin Control Register n (PORTB_PCR14) 32 R/W See section 11.5.1/248
4004_A03C Pin Control Register n (PORTB_PCR15) 32 R/W See section 11.5.1/248
4004_A040 Pin Control Register n (PORTB_PCR16) 32 R/W See section 11.5.1/248
4004_A044 Pin Control Register n (PORTB_PCR17) 32 R/W See section 11.5.1/248
4004_A048 Pin Control Register n (PORTB_PCR18) 32 R/W See section 11.5.1/248
4004_A04C Pin Control Register n (PORTB_PCR19) 32 R/W See section 11.5.1/248
4004_A050 Pin Control Register n (PORTB_PCR20) 32 R/W See section 11.5.1/248
4004_A054 Pin Control Register n (PORTB_PCR21) 32 R/W See section 11.5.1/248
4004_A058 Pin Control Register n (PORTB_PCR22) 32 R/W See section 11.5.1/248
4004_A05C Pin Control Register n (PORTB_PCR23) 32 R/W See section 11.5.1/248
4004_A060 Pin Control Register n (PORTB_PCR24) 32 R/W See section 11.5.1/248
4004_A064 Pin Control Register n (PORTB_PCR25) 32 R/W See section 11.5.1/248
4004_A068 Pin Control Register n (PORTB_PCR26) 32 R/W See section 11.5.1/248
4004_A06C Pin Control Register n (PORTB_PCR27) 32 R/W See section 11.5.1/248
4004_A070 Pin Control Register n (PORTB_PCR28) 32 R/W See section 11.5.1/248
4004_A074 Pin Control Register n (PORTB_PCR29) 32 R/W See section 11.5.1/248
4004_A078 Pin Control Register n (PORTB_PCR30) 32 R/W See section 11.5.1/248
4004_A07C Pin Control Register n (PORTB_PCR31) 32 R/W See section 11.5.1/248
4004_A080 Global Pin Control Low Register (PORTB_GPCLR) 32
W
(always
reads 0)
0000_0000h 11.5.2/251
Table continues on the next page...
Chapter 11 Port Control and Interrupts (PORT)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 243
