NXP Semiconductors K22F series User Manual

PORT memory map (continued)
Absolute
address
(hex)
Register name
Width
(in bits)
Access Reset value
Section/
page
4004_A084 Global Pin Control High Register (PORTB_GPCHR) 32
W
(always
reads 0)
0000_0000h 11.5.3/251
4004_A0A0 Interrupt Status Flag Register (PORTB_ISFR) 32 w1c 0000_0000h 11.5.4/252
4004_A0C0 Digital Filter Enable Register (PORTB_DFER) 32 R/W 0000_0000h 11.5.5/252
4004_A0C4 Digital Filter Clock Register (PORTB_DFCR) 32 R/W 0000_0000h 11.5.6/253
4004_A0C8 Digital Filter Width Register (PORTB_DFWR) 32 R/W 0000_0000h 11.5.7/253
4004_B000 Pin Control Register n (PORTC_PCR0) 32 R/W See section 11.5.1/248
4004_B004 Pin Control Register n (PORTC_PCR1) 32 R/W See section 11.5.1/248
4004_B008 Pin Control Register n (PORTC_PCR2) 32 R/W See section 11.5.1/248
4004_B00C Pin Control Register n (PORTC_PCR3) 32 R/W See section 11.5.1/248
4004_B010 Pin Control Register n (PORTC_PCR4) 32 R/W See section 11.5.1/248
4004_B014 Pin Control Register n (PORTC_PCR5) 32 R/W See section 11.5.1/248
4004_B018 Pin Control Register n (PORTC_PCR6) 32 R/W See section 11.5.1/248
4004_B01C Pin Control Register n (PORTC_PCR7) 32 R/W See section 11.5.1/248
4004_B020 Pin Control Register n (PORTC_PCR8) 32 R/W See section 11.5.1/248
4004_B024 Pin Control Register n (PORTC_PCR9) 32 R/W See section 11.5.1/248
4004_B028 Pin Control Register n (PORTC_PCR10) 32 R/W See section 11.5.1/248
4004_B02C Pin Control Register n (PORTC_PCR11) 32 R/W See section 11.5.1/248
4004_B030 Pin Control Register n (PORTC_PCR12) 32 R/W See section 11.5.1/248
4004_B034 Pin Control Register n (PORTC_PCR13) 32 R/W See section 11.5.1/248
4004_B038 Pin Control Register n (PORTC_PCR14) 32 R/W See section 11.5.1/248
4004_B03C Pin Control Register n (PORTC_PCR15) 32 R/W See section 11.5.1/248
4004_B040 Pin Control Register n (PORTC_PCR16) 32 R/W See section 11.5.1/248
4004_B044 Pin Control Register n (PORTC_PCR17) 32 R/W See section 11.5.1/248
4004_B048 Pin Control Register n (PORTC_PCR18) 32 R/W See section 11.5.1/248
4004_B04C Pin Control Register n (PORTC_PCR19) 32 R/W See section 11.5.1/248
4004_B050 Pin Control Register n (PORTC_PCR20) 32 R/W See section 11.5.1/248
4004_B054 Pin Control Register n (PORTC_PCR21) 32 R/W See section 11.5.1/248
4004_B058 Pin Control Register n (PORTC_PCR22) 32 R/W See section 11.5.1/248
4004_B05C Pin Control Register n (PORTC_PCR23) 32 R/W See section 11.5.1/248
4004_B060 Pin Control Register n (PORTC_PCR24) 32 R/W See section 11.5.1/248
4004_B064 Pin Control Register n (PORTC_PCR25) 32 R/W See section 11.5.1/248
4004_B068 Pin Control Register n (PORTC_PCR26) 32 R/W See section 11.5.1/248
4004_B06C Pin Control Register n (PORTC_PCR27) 32 R/W See section 11.5.1/248
4004_B070 Pin Control Register n (PORTC_PCR28) 32 R/W See section 11.5.1/248
4004_B074 Pin Control Register n (PORTC_PCR29) 32 R/W See section 11.5.1/248
4004_B078 Pin Control Register n (PORTC_PCR30) 32 R/W See section 11.5.1/248
Table continues on the next page...
Memory map and register definition
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
244 NXP Semiconductors
