PORT memory map (continued)
Absolute
address
(hex)
Register name
Width
(in bits)
Access Reset value
Section/
page
4004_B07C Pin Control Register n (PORTC_PCR31) 32 R/W See section 11.5.1/248
4004_B080 Global Pin Control Low Register (PORTC_GPCLR) 32
W
(always
reads 0)
0000_0000h 11.5.2/251
4004_B084 Global Pin Control High Register (PORTC_GPCHR) 32
W
(always
reads 0)
0000_0000h 11.5.3/251
4004_B0A0 Interrupt Status Flag Register (PORTC_ISFR) 32 w1c 0000_0000h 11.5.4/252
4004_B0C0 Digital Filter Enable Register (PORTC_DFER) 32 R/W 0000_0000h 11.5.5/252
4004_B0C4 Digital Filter Clock Register (PORTC_DFCR) 32 R/W 0000_0000h 11.5.6/253
4004_B0C8 Digital Filter Width Register (PORTC_DFWR) 32 R/W 0000_0000h 11.5.7/253
4004_C000 Pin Control Register n (PORTD_PCR0) 32 R/W See section 11.5.1/248
4004_C004 Pin Control Register n (PORTD_PCR1) 32 R/W See section 11.5.1/248
4004_C008 Pin Control Register n (PORTD_PCR2) 32 R/W See section 11.5.1/248
4004_C00C Pin Control Register n (PORTD_PCR3) 32 R/W See section 11.5.1/248
4004_C010 Pin Control Register n (PORTD_PCR4) 32 R/W See section 11.5.1/248
4004_C014 Pin Control Register n (PORTD_PCR5) 32 R/W See section 11.5.1/248
4004_C018 Pin Control Register n (PORTD_PCR6) 32 R/W See section 11.5.1/248
4004_C01C Pin Control Register n (PORTD_PCR7) 32 R/W See section 11.5.1/248
4004_C020 Pin Control Register n (PORTD_PCR8) 32 R/W See section 11.5.1/248
4004_C024 Pin Control Register n (PORTD_PCR9) 32 R/W See section 11.5.1/248
4004_C028 Pin Control Register n (PORTD_PCR10) 32 R/W See section 11.5.1/248
4004_C02C Pin Control Register n (PORTD_PCR11) 32 R/W See section 11.5.1/248
4004_C030 Pin Control Register n (PORTD_PCR12) 32 R/W See section 11.5.1/248
4004_C034 Pin Control Register n (PORTD_PCR13) 32 R/W See section 11.5.1/248
4004_C038 Pin Control Register n (PORTD_PCR14) 32 R/W See section 11.5.1/248
4004_C03C Pin Control Register n (PORTD_PCR15) 32 R/W See section 11.5.1/248
4004_C040 Pin Control Register n (PORTD_PCR16) 32 R/W See section 11.5.1/248
4004_C044 Pin Control Register n (PORTD_PCR17) 32 R/W See section 11.5.1/248
4004_C048 Pin Control Register n (PORTD_PCR18) 32 R/W See section 11.5.1/248
4004_C04C Pin Control Register n (PORTD_PCR19) 32 R/W See section 11.5.1/248
4004_C050 Pin Control Register n (PORTD_PCR20) 32 R/W See section 11.5.1/248
4004_C054 Pin Control Register n (PORTD_PCR21) 32 R/W See section 11.5.1/248
4004_C058 Pin Control Register n (PORTD_PCR22) 32 R/W See section 11.5.1/248
4004_C05C Pin Control Register n (PORTD_PCR23) 32 R/W See section 11.5.1/248
4004_C060 Pin Control Register n (PORTD_PCR24) 32 R/W See section 11.5.1/248
4004_C064 Pin Control Register n (PORTD_PCR25) 32 R/W See section 11.5.1/248
4004_C068 Pin Control Register n (PORTD_PCR26) 32 R/W See section 11.5.1/248
4004_C06C Pin Control Register n (PORTD_PCR27) 32 R/W See section 11.5.1/248
Table continues on the next page...
Chapter 11 Port Control and Interrupts (PORT)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 245
