types that do not trigger Chip Reset not VLLS. See the
Introduction details for more information.
Address: 4007_C000h base + 4h offset = 4007_C004h
Bit 7 6 5 4 3 2 1 0
Read
WUME7 WUME6 WUME5 WUME4 WUME3 WUME2 WUME1 WUME0
Write
Reset
0 0 0 0 0 0 0 0
LLWU_ME field descriptions
Field Description
7
WUME7
Wakeup Module Enable For Module 7
Enables an internal module as a wakeup source input.
0 Internal module flag not used as wakeup source
1 Internal module flag used as wakeup source
6
WUME6
Wakeup Module Enable For Module 6
Enables an internal module as a wakeup source input.
0 Internal module flag not used as wakeup source
1 Internal module flag used as wakeup source
5
WUME5
Wakeup Module Enable For Module 5
Enables an internal module as a wakeup source input.
0 Internal module flag not used as wakeup source
1 Internal module flag used as wakeup source
4
WUME4
Wakeup Module Enable For Module 4
Enables an internal module as a wakeup source input.
0 Internal module flag not used as wakeup source
1 Internal module flag used as wakeup source
3
WUME3
Wakeup Module Enable For Module 3
Enables an internal module as a wakeup source input.
0 Internal module flag not used as wakeup source
1 Internal module flag used as wakeup source
2
WUME2
Wakeup Module Enable For Module 2
Enables an internal module as a wakeup source input.
0 Internal module flag not used as wakeup source
1 Internal module flag used as wakeup source
1
WUME1
Wakeup Module Enable for Module 1
Enables an internal module as a wakeup source input.
0 Internal module flag not used as wakeup source
1 Internal module flag used as wakeup source
Table continues on the next page...
Memory map/register definition
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
388 NXP Semiconductors
