FTFA_FSTAT field descriptions (continued)
Field Description
0 No protection violation detected
1 Protection violation detected
3–1
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
0
MGSTAT0
Memory Controller Command Completion Status Flag
The MGSTAT0 status flag is set if an error is detected during execution of a flash command or during the
flash reset sequence. As a status flag, this field cannot (and need not) be cleared by the user like the other
error flags in this register.
The value of the MGSTAT0 bit for "command-N" is valid only at the end of the "command-N" execution
when CCIF=1 and before the next command has been launched. At some point during the execution of
"command-N+1," the previous result is discarded and any previous error is cleared.
29.3.3.2 Flash Configuration Register (FTFA_FCNFG)
This register provides information on the current functional state of the flash memory
module.
The erase control bits (ERSAREQ and ERSSUSP) have write restrictions. The
unassigned bits read as noted and are not writable.
Address:
4002_0000h base + 1h offset = 4002_0001h
Bit 7 6 5 4 3 2 1 0
Read
CCIE RDCOLLIE
ERSAREQ
ERSSUSP
0 0 0 0
Write
Reset
0 0 0 0 0 0 0 0
FTFA_FCNFG field descriptions
Field Description
7
CCIE
Command Complete Interrupt Enable
Controls interrupt generation when a flash command completes.
0 Command complete interrupt disabled
1 Command complete interrupt enabled. An interrupt request is generated whenever the FSTAT[CCIF]
flag is set.
6
RDCOLLIE
Read Collision Error Interrupt Enable
Controls interrupt generation when a flash memory read collision error occurs.
0 Read collision error interrupt disabled
1 Read collision error interrupt enabled. An interrupt request is generated whenever a flash memory
read collision error is detected (see the description of FSTAT[RDCOLERR]).
5
ERSAREQ
Erase All Request
Table continues on the next page...
Memory Map and Registers
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
638 NXP Semiconductors
