ADCx_SC1n field descriptions (continued)
Field Description
01000 When DIFF=0, AD8 is selected as input; when DIFF=1, it is reserved.
01001 When DIFF=0, AD9 is selected as input; when DIFF=1, it is reserved.
01010 When DIFF=0, AD10 is selected as input; when DIFF=1, it is reserved.
01011 When DIFF=0, AD11 is selected as input; when DIFF=1, it is reserved.
01100 When DIFF=0, AD12 is selected as input; when DIFF=1, it is reserved.
01101 When DIFF=0, AD13 is selected as input; when DIFF=1, it is reserved.
01110 When DIFF=0, AD14 is selected as input; when DIFF=1, it is reserved.
01111 When DIFF=0, AD15 is selected as input; when DIFF=1, it is reserved.
10000 When DIFF=0, AD16 is selected as input; when DIFF=1, it is reserved.
10001 When DIFF=0, AD17 is selected as input; when DIFF=1, it is reserved.
10010 When DIFF=0, AD18 is selected as input; when DIFF=1, it is reserved.
10011 When DIFF=0, AD19 is selected as input; when DIFF=1, it is reserved.
10100 When DIFF=0, AD20 is selected as input; when DIFF=1, it is reserved.
10101 When DIFF=0, AD21 is selected as input; when DIFF=1, it is reserved.
10110 When DIFF=0, AD22 is selected as input; when DIFF=1, it is reserved.
10111 When DIFF=0, AD23 is selected as input; when DIFF=1, it is reserved.
11000 Reserved.
11001 Reserved.
11010 When DIFF=0, Temp Sensor (single-ended) is selected as input; when DIFF=1, Temp Sensor
(differential) is selected as input.
11011 When DIFF=0,Bandgap (single-ended) is selected as input; when DIFF=1, Bandgap (differential)
is selected as input.
11100 Reserved.
11101 When DIFF=0,V
REFSH
is selected as input; when DIFF=1, -V
REFSH
(differential) is selected as
input. Voltage reference selected is determined by SC2[REFSEL].
11110 When DIFF=0,V
REFSL
is selected as input; when DIFF=1, it is reserved. Voltage reference
selected is determined by SC2[REFSEL].
11111 Module is disabled.
Chapter 34 Analog-to-Digital Converter (ADC)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 771
