Page #911 background imageLoading...
Page #911 background image
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R
0
CH7F
CH6F
CH5F
CH4F
CH3F
CH2F
CH1F
CH0F
W
0 0 0 0 0 0 0 0
Reset
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
FTMx_STATUS field descriptions
Field Description
31–8
Reserved
This field is reserved.
This read-only field is reserved and always has the value 0.
7
CH7F
Channel 7 Flag
See the register description.
0 No channel event has occurred.
1 A channel event has occurred.
6
CH6F
Channel 6 Flag
See the register description.
0 No channel event has occurred.
1 A channel event has occurred.
5
CH5F
Channel 5 Flag
See the register description.
0 No channel event has occurred.
1 A channel event has occurred.
4
CH4F
Channel 4 Flag
See the register description.
0 No channel event has occurred.
1 A channel event has occurred.
3
CH3F
Channel 3 Flag
See the register description.
0 No channel event has occurred.
1 A channel event has occurred.
2
CH2F
Channel 2 Flag
See the register description.
Table continues on the next page...
Chapter 39 FlexTimer Module (FTM)
K22F Sub-Family Reference Manual, Rev. 4, 08/2016
NXP Semiconductors 911
