User manual Rev. 3 — 19 December 2013 298 of 841

NXP Semiconductors

UM10360

Chapter 13: LPC176x/5x USB OTG

5. Follow the appropriate steps in Section 11.13 “USB device controller initialization” to

initialize the device controller.

6. Follow the guidelines given in the OpenHCI specification for initializing the host

controller.
