User manual Rev. 3 — 19 December 2013 428 of 841

NXP Semiconductors

UM10360

Chapter 18: LPC176x/5x SSP0/1

Table 379: SSPn DMA Control Register (SSP0DMACR - address 0x4008 8024, SSP1DMACR -

0x4003 0024) bit description

Bit Symbol Description Reset

Value

0 Receive DMA Enable

(RXDMAE)

When this bit is set to one 1, DMA for the receive FIFO is

enabled, otherwise receive DMA is disabled.

1 Transmit DMA Enable

(TXDMAE)

When this bit is set to one 1, DMA for the transmit FIFO is

enabled, otherwise transmit DMA is disabled

31:2 - Reserved, user software should not write ones to reserved

bits. The value read from a reserved bit is not defined.
