User manual Rev. 3 — 19 December 2013 623 of 841

NXP Semiconductors

UM10360

Chapter 32: LPC176x/5x Flash memory interface and programming

If any CRP mode is enabled and access to the chip is allowed via the ISP, an unsupported

or restricted ISP command will be terminated with return code

CODE_READ_PROTECTION_ENABLED.

Table 569. Code Read Protection hardware/software interaction

CRP option User Code

Valid

P2.10 pin at

reset

JTAG enabled LPC176x/5x

enters ISP

mode

partial flash

update in ISP

mode

None No X Yes Yes Yes

Yes High Yes No NA

Yes Low Yes Yes Yes

CRP1 No x No Yes Yes

YesHighNoNoNA

Yes Low No Yes Yes

CRP2 No x No Yes No

YesHighNoNoNA

Yes Low No Yes No

CRP3 No x No Yes No

Yes x No No NA
