9. Remove the upper left cover [A] ( ×1).
• The screw removed is used again in step 15.
10. Open the right door, and then remove the small cover [A].
11. Remove the screw and connector, and then remove the front upper cover [A].
Bridge Unit BU3070 (D685)
191
