Extended interrupt and event controller (EXTI) RM0444
326/1390 RM0444 Rev 5
13.5.4 EXTI rising edge pending register 1 (EXTI_RPR1)
Address offset: 0x00C
Reset value: 0x0000 0000
Contains only register bits for configurable events.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
SWI
20
Res.
SWI
18
SWI
17
SWI
16
rw rw rw rw
1514131211109 8 7654321 0
SWI
15
SWI
14
SWI
13
SWI
12
SWI
11
SWI
10
SWI9 SWI8 SWI7 SWI6 SWI5 SWI4 SWI3 SWI2 SWI1 SWI0
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:21 Reserved, must be kept at reset value.
Bit 20 SWI20: Software rising edge event trigger on line 20
(1)
.
Setting this bit by software triggers a rising edge event on the corresponding line, resulting in
an interrupt, independently of EXTI_RTSR1 and EXTI_FTSR1 settings. This bit is
automatically cleared by hardware. Reading this bit always returns 0.
0: No effect
1: Rising edge event generated on the corresponding line, followed by an interrupt
The SWI20 bit is only available in STM32G0B1xx and STM32G0C1xx. It is reserved in all
the other devices.
Bit 19 Reserved, must be kept at reset value.
Bits 18:0 SWIx: Software rising edge event trigger on line x (x = 18 to 0)
Setting of any bit by software triggers a rising edge event on the corresponding line x,
resulting in an interrupt, independently of EXTI_RTSR1 and EXTI_FTSR1 settings. The bits
are automatically cleared by HW. Reading of any bit always returns 0.
0: No effect
1: Rising edge event generated on the corresponding line, followed by an interrupt
The SW18 and SW17 bits are only available in STM32G071xx and STM32G081xx as well
as STM32G0B1xx and STM32G0C1xx. They are reserved in STM32G031xx and
STM32G041xx as well as STM32G051xx and STM32G061xx.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. RPIF20 Res. RPIF18 RPIF17 RPIF16
rc_w1 rc_w1 rc_w1 rc_w1
1514131211109 8 7654321 0
RPIF15 RPIF14 RPIF13 RPIF12 RPIF11 RPIF10 RPIF9 RPIF8 RPIF7 RPIF6 RPIF5 RPIF4 RPIF3 RPIF2 RPIF1 RPIF0
rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1
