RM0444 Universal synchonous receiver transmitter (USART)

1138

Table 180. USART / LPUART features

USART / LPUART modes/features

(1)

Full feature set Basic feature set

Low-power

feature set

Hardware flow control for modem X X X

Continuous communication using DMA X X X

Multiprocessor communication X X X

Synchronous mode (Master/Slave) X X -

Smartcard mode X - -

Single-wire Half-duplex communication X X X

IrDA SIR ENDEC block X - -

LIN mode X - -

Dual clock domain and wakeup from low-power mode X - X

Receiver timeout interrupt X - -

Modbus communication X - -

Auto baud rate detection X - -

Driver Enable X X X

USART data length 7, 8 and 9 bits

Tx/Rx FIFO X - X

Tx/Rx FIFO size 8 - 8

Prescaler X - X

1. X = supported.
