RM0444 Rev 5 827/1390
RM0444 General-purpose timers (TIM15/TIM16/TIM17)
830
25.6.20 TIM17 input selection register (TIM17_TISEL)
Address offset: 0x68
Reset value: 0x0000 0000
Bit 9 BKINP: BRK BKIN input polarity
This bit selects the BKIN alternate function input sensitivity. It must be programmed together
with the BKP polarity bit.
0: BKIN input is active low
1: BKIN input is active high
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Bits 8:4 Reserved, must be kept at reset value.
Bit 3 BKCMP3E: BRK COMP3 enable
This bit enables the COMP3 for the timer’s BRK input. COMP3 output is ‘ORed’ with the
other BRK sources.
0: COMP3 input disabled
1: COMP3 input enabled
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Note: This bit is available on STM32G0B1xx and STM32G0C1xx salestypes only, reserved
otherwise.
Bit 2 BKCMP2E: BRK COMP2 enable
This bit enables the COMP2 for the timer’s BRK input. COMP2 output is ‘ORed’ with the
other BRK sources.
0: COMP2 input disabled
1: COMP2 input enabled
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Bit 1 BKCMP1E: BRK COMP1 enable
This bit enables the COMP1 for the timer’s BRK input. COMP1 output is ‘ORed’ with the
other BRK sources.
0: COMP1 input disabled
1: COMP1 input enabled
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
Bit 0 BKINE: BRK BKIN input enable
This bit enables the BKIN alternate function input for the timer’s BRK input. BKIN input is
‘ORed’ with the other BRK sources.
0: BKIN input disabled
1: BKIN input enabled
Note: This bit can not be modified as long as LOCK level 1 has been programmed (LOCK bits
in TIMx_BDTR register).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. TI1SEL[3:0]
rw rw rw rw
