RM0444 Rev 5 697/1390
RM0444 General-purpose timers (TIM2/TIM3/TIM4)
701
22.4.30 TIM4 timer input selection register (TIM4_TISEL)
Address offset: 0x68
Reset value: 0x0000 0000
Bits 31:20 Reserved, must be kept at reset value.
Bits 19:16 TI3SEL[3:0]: TI3[0] to TI3[15] input selection
These bits select the TI3[0] to TI3[15] input source.
0000: TIM3_CH3 input
0001: COMP3 output
Others: Reserved
Note: Available on STM32G0B1xx and STM32G0C1xx salestypes only, otherwise reserved.
Bits 15:12 Reserved, must be kept at reset value.
Bits 11:8 TI2SEL[3:0]: TI2[0] to TI2[15] input selection
These bits select the TI2[0] to TI2[15] input source.
0000: TIM3_CH2 input
0001: COMP2 output
Others: Reserved
Bits 7:4 Reserved, must be kept at reset value.
Bits 3:0 TI1SEL[3:0]: TI1[0] to TI1[15] input selection
These bits select the TI1[0] to TI1[15] input source.
0000: TIM3_CH1 input
0001: COMP1 output
Others: Reserved
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. TI3SEL[3:0]
rw rw rw rw
1514131211109876543210
Res. Res. Res. Res. TI2SEL[3:0] Res. Res. Res. Res. TI1SEL[3:0]
rw rw rw rw rw rw rw rw
Bits 31:20 Reserved, must be kept at reset value.
Bits 19:16 TI3SEL[3:0]: TI3[0] to TI3[15] input selection
These bits select the TI3[0] to TI3[15] input source.
0000: TIM4_CH3 input
0001: COMP3 output
Others: Reserved
Note: Available on STM32G0B1xx and STM32G0C1xx salestypes only, otherwise reserved.
Bits 15:12 Reserved, must be kept at reset value.
