RM0444 Rev 5 311/1390
RM0444 DMA request multiplexer (DMAMUX)
313
11.6.5 DMAMUX request generator interrupt status register
(DMAMUX_RGSR)
Address offset: 0x140
Reset value: 0x0000 0000
11.6.6 DMAMUX request generator interrupt clear flag register
(DMAMUX_RGCFR)
Address offset: 0x144
Reset value: 0x0000 0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. OF3 OF2 OF1 OF0
rrrr
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 OF[3:0]: Trigger overrun event flag
The flag is set when a new trigger event occurs on DMA request generator channel x, before
the request counter underrun (the internal request counter programmed via the GNBREQ
field of the DMAMUX_RGxCR register).
The flag is cleared by writing 1 to the corresponding COFx bit in the DMAMUX_RGCFR
register.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. COF3 COF2 COF1 COF0
wwww
Bits 31:4 Reserved, must be kept at reset value.
Bits 3:0 COF[3:0]: Clear trigger overrun event flag
Writing 1 in each bit clears the corresponding overrun flag OFx in the DMAMUX_RGSR
register.
