Embedded Flash memory (FLASH) RM0444
70/1390 RM0444 Rev 5
Main
memory
0x0801 F800 - 0x0801 FFFF 2 K
-
Page 63
... ... ...
0x0801 0000 - 0x0801 07FF 2 K Page 32
0x0800 F800 - 0x0800 FFFF 2 K Page 31
... ... ...
0x0800 8000 - 0x0800 87FF 2 K Page 16
0x0800 7800 - 0x0800 7FFF 2 K Page 15 Page 15
... ... ... ...
0x0800 4000 - 0x0800 47FF 2 K Page 8 Page 8
0x0800 3800 - 0x0800 3FFF 2 K Page 7 Page 7
... ... ... ...
0x0800 1000 - 0x0800 17FF 2 K Page 2 Page 2
0x0800 0800 - 0x0800 0FFF 2 K Page 1 Page 1
0x0800 0000 - 0x0800 07FF 2 K Page 0 Page 0
Table 9. Flash memory organization for single-bank devices (continued)
Area Addresses
Size
(bytes)
16 Kbyte
devices
32 Kbyte
devices
64 Kbyte
devices
128 Kbyte
devices
Table 10. Flash memory organization for 256 Kbytes dual-bank devices
Area Addresses Size (bytes)
Memory
type
Information
block
Bank 1 0x1FFF 7800 - 0x1FFF 787F 128 Option bytes
Bank 1 0x1FFF 7000 - 0x1FFF 73FF 1 K OTP area
Bank 1 0x1FFF 0000 - 0x1FFF 6FFF 28 K System memory
Main
memory
Bank 2
0x0803 F800 - 0x0803 FFFF 2 K Page 319
... ... ...
0x0802 1000 - 0x0802 17FF 2 K Page 258
0x0802 0800 - 0x0802 0FFF 2 K Page 257
0x0802 0000 - 0x0802 07FF 2 K Page 256
Bank 1
0x0801 F800 - 0x0801 FFFF 2 K Page 63
... ... ...
0x0800 1000 - 0x0800 17FF 2 K Page 2
0x0800 0800 - 0x0800 0FFF 2 K Page 1
0x0800 0000 - 0x0800 07FF 2 K Page 0
