Direct memory access controller (DMA) RM0444

278/1390 RM0444 Rev 5

10.3 DMA implementation

10.3.1 DMA

The devices incorporate one or two DMA controller instances. The following implementation

table shows the number of DMA channels for either instance. A dash indicates that the

instance is not implemented.

10.3.2 DMA request mapping

The DMA controller is connected to DMA requests from the AHB/APB peripherals through

the DMAMUX peripheral.

For the mapping of the different requests, refer to the Section 11.3: DMAMUX

implementation.

10.4 DMA functional description

10.4.1 DMA block diagram

Table 46. DMA implementation

Number of channels

STM32G031xx

STM32G041xx

STM32G051xx

STM32G061xx

STM32G071xx

STM32G081xx

STM32G0B1xx

STM32G0C1xx

DMA1 5 7 7

DMA2 - - 5
