RM0444 Rev 5 1027/1390

RM0444 Universal synchonous receiver transmitter (USART)

1138

Figure 324. Break detection in LIN mode (11-bit break length - LBDL bit is set)

MSv31156V1

Idle Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6 Bit7 Bit8 Bit9 Bit10 Idle

0000 000 0001

Case 1: break signal not long enough => break discarded, LBDF is not set

RX line

Capture strobe

Break state

machine

Read samples

Idle Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6 Bit7 Bit8 Bit9 B10 Idle

0000 000 0000

Case 2: break signal just long enough => break detected, LBDF is set

RX line

Capture strobe

Break state

machine

Read samples

Break frame

Delimiter is immediate

LBDF

Idle Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6 Bit7 Bit8 Bit9 Bit10 Idle

0000 000 0000

Case 3: break signal long enough => break detected, LBDF is set

RX line

Capture strobe

Break state

machine

Read samples

Break frame

LBDF

wait delimiter
