RM0444 Low-power universal asynchronous receiver transmitter (LPUART)

1138

Figure 353. Wakeup event verified (wakeup event = address match,

FIFO disabled)

Figure 354 shows the behavior when the wakeup event is not verified.

Figure 354. Wakeup event not verified (wakeup event = address match,

FIFO disabled)

Note: The above figures are valid when address match or any received frame is used as wakeup

event. In the case the wakeup event is the start bit detection, the LPUART sends the

wakeup event to the MCU at the end of the start bit.

MSv40860V2

lpuart_ker_ck

RX line

Idle

Start bit

Rx data 1 Rx data 2

Start bit

Stop bit

Startup time

OFF

Low-power mode Run mode

Address match event WUF =’1'

LPUART sends a wakeup event to the MCU

Data reception goes on

MSv40861V2

lpuart_ker_ck

RX line

Idle

Start bit

Rx data 1

Stop bit

Startup time

OFF

Low-power mode

Address does not match

Idle

OFF
